3 Acrylic Poster 4 Double Panel 5 Panel Supports 6 Aluminium Rail
Holder Support - Suitable for 4mm and 7mm Screw Fixing
thick substrates:
- Acrylic poster holders have wings to - Suitable for 4mm and 7mm thick - 4mm - 10mm diam. x 15.5mm - Fix to ceiling or walls – cable
take panel support fixings substrates: - 7mm - 16mm diam. x 20.5mm fixings slot in and screw in
- Available landscape or portrait - 4mm - 10mm diam. x 20mm to place
- Available in five sizes from A1 to A5 - 7mm - 16mm diam. x 43mm with - Custom sizes available
rotating feature for multi-angle fixing - Complete with moulded
Model Code
end caps
A1 AH411L/P
A2 AH412L/P
Model Code Model Code
A3 AH413L/P Model Code
10 mm (ø) P0122 10 mm (ø) P0113
A4 AH414L/P 1 metre PR102
POS Signage
A5 AH415L/P 16 mm (ø) P0121 16 mm (ø) P0112 2 metres PR101

7 Adjustable 8 Rotating Edge 9 Compact Variable 10 Compact Variable
Fixing Cable Stand-offs Wall Plate Cable Fixing

- 4m x 1.5mm Strata adjustable - Edge stand-offs eliminate the need - 16mm diam. x 25mm, - 16mm diam. x 25mm, 180°
cable kit for an aperture in the substrate - 180° variable fixing variable fixing
- Supplied with rail fixings - Suitable for 2mm - 10mm thick - 360° free moving or lockable - Choice or rail fix or screw
- Can be fixed wall to wall, floor substrates in rail or screw options - Suitable for fixing to walls fix options
to ceiling, direct to wall - extra - Choice of sizes: 34mm x 16mm diam. or ceilings - Cannot be used with
components required and 34mm x 25mm diam. with distance PO110 cable kit
from wall or ceiling 18.5mm approx.
Code (h) x (ø) mm Code (h) x (ø) mm Code (h) x (ø) mm Model Code
P0109 4000 x 1.5 mm P0119 34 x 16 mm P0106 25 x 16 mm Rail P0107
P0120 34 x 25 mm Screw P0108

11 Floor to Ceiling 12 Insert for Screw 13 Insert Rail Fixing
Fixing Cable Fixing

- 4m x 1.5mm Strata adjustable cable kit - Suitable for PO109 Strata - Suitable for PO109 Strata
- Supplied with screw Cable Kits and Stand-off Cable Kits and Stand-off
- Not suitable for compact components components
variable fixings

Code (h) x (ø) mm Code Code
P0110 4000 x 1.5 mm P0116 P0115

DISPLAY SOLUTIONS // 45
